Yale GLP090VX Forklift Specifications

Make: Yale
Model: GLP090VX
Type: Pneumatic Tire Internal Combustion
Basic Capacity (lbs/kg): 9000/4090
Load Center (in/mm): 24/610
Power: LP Gas
Engine: PSI 4.3L / Kubota 3.8L LPG
Tire Type: Pneumatic
Tilt (forward/back): 6.0/10.0 degrees
Length to Fork Face (in/mm): 117.2/2977
Overall Width - Standard (in/mm): 55.2/1402
Overall Width - Wide (in/mm): 58.5/1485
Height to Top of Overhead Guard - Standard (in/mm): 89/2260
Height to Top of Overhead Guard - Optional (in/mm): 87/2193
Minimum turning radius (in/mm): 103.1/2619
Weight with two stage mast & PSI 4.3L (lbs/kg): 13920/6314
Weight with two stage mast & Kubota 3.8L 4.3L (lbs/kg): 14118/6404
Front Tire Size: 250 x 15 - 20 Ply
Rear Tire Size: 7.00 x 12 - 14 Ply
Wheelbase (in/mm): 72/1830
