Yale OS030BF

Forklift Specifications

Attribute Value
Make Yale
Model OS030BF
Forklift Type Order Picker
Fuel Electric
Voltage 24/36
Capacity (lbs/kg) 3000/1361
Load Center (in/mm) 24/609
Headlength (in/mm) 73.3/1863
Operator Platform Size – Length/Width (in/mm) 40/27.5 / 1016/698
Base Width (in/mm) 40.7 or 48.3 /1035 or 1227
Turning Radius – Minimum outside (in/mm) 67.7/1719
Base Arm Clearance (in/mm) 2.1/52
Travel Speed 24V and 36V (mph/kmh) 6.5/10.5
Weight w/o Battery (lb/kg) 3845/1744
Tire Size – Drive (in – mm) 13.5/5 – 343/140
Tire Size – Load Wheel (in – mm) 5.0/3.0 – 127/76
Wheelbase (in/mm) 57.1/1450

Related Products

Mollit consequat adipisicing in commodo fugiat. Quis voluptate pariatur ex mollit exercitation.

24 Volts

Attribute Value
Battery Box Dimensions 39.00" x 14.60" x 31.50"
Recommended A.H 960
Connector SB350 Red

36 Volts

Attribute Value
Battery Box Dimensions 39.00" x 14.60" x 31.50"
Recommended A.H 600
Connector SB350 Red
