| Attribute | Value |
|---|---|
| Make | Yale |
| Model | NR045EB |
| Forklift Type | Reach Truck |
| Basic Capacity (lb/kg) | 4500/2041 |
| Load Center (in/mm) | 24/610 |
| Power | Electric – 36 Volt |
| Tilt – standard (forward/back) | 3/4 degrees |
| Length to Fork Face 16.5" Battery Compartment (in/mm) | 57.47/1460 |
| Length to Fork Face 18.5" Battery Compartment (in/mm) | 59.6/1514 |
| Length to Fork Face 21.5" Battery Compartment (in/mm) | 62.59/1590 |
| Chassis Width (in/mm) | 42.8/1087 |
| Turning Radius 18.5" Battery Compartment (in/mm) | 69.9/1775 |
| Turning Radius 21.5" Battery Compartment (in/mm) | 72.9/1852 |
| Travel Speed – Rearward (chassis first) – empty / rated load (mph) | 7.4/6.5 |
| Travel Speed – Forward ( forks first) – empty / rated load (mph) | 7.4/5.8 |
| Size – front load wheels | 5 x 3.9 |
| Size – Drive Tire | 13.5 x 5.5 |
| Size – Caster Wheel | 7.9 x 2.2 |
| Battery Type | Lead Acid |
| Traction motor rating – 60 minute rating (hp/kw) | 8.7/6.5 |
| Hoist motor rating – 5 minute rating (kp/kw) | 20.7/15.4 |
| Wheelbase – 16.5" Battery Compartment (in/mm) | 57.36/1457 |
| Wheelbase – 18.5" Battery Compartment (in/mm) | 59.37/1508 |
| Wheelbase – 21.5" Battery Compartment (in/mm) | 62.36/1584 |
Yale NR045EB Forklift Battery and Charger Information
Mollit consequat adipisicing in commodo fugiat. Quis voluptate pariatur ex mollit exercitation.
16.5" Battery Box – 36 Volts
| Attribute | Value |
|---|---|
| Compartment Dimensions – in(mm) | 39.00" x 16.50" x 31.50" |
| Max Amp Hours | 930Ah |
| Minimum Weight – lb(kg) | 1850/839 |
18.5" Battery Box – 36 Volts
| Attribute | Value |
|---|---|
| Compartment Dimensions – in(mm) | 39.00" x 18.50" x 31.50" |
| Max Amp Hours | 1085Ah |
| Minimum Weight – lb(kg) | 2200lbs |
21.5" Battery Box – 36 Volts
| Attribute | Value |
|---|---|
| Compartment Dimensions – in(mm) | 39.00" x 21.50" x 31.50" |
| Max Amp Hours | 1240Ah |
| Minimum Weight – lb(kg) | 2500lbs |
