Yale GP070VX

Attribute Value
Make Yale
Model GP070VX
Type Pneumatic Tire Internal Combustion
Basic Capacity (lbs/kg) 7000/3175
Load Center (in/mm) 24/610
Power LP Gas/Dual Fuel/Diesel
Engine PSI 2.4L/Kubota2.5L/Kubota 2.4L Tier 4 Final
Tire Type Pneumatic
Tilt (forward/back) 6.0/6.0 degrees
Length to Fork Face (in/mm) 107.6/2734
Overall Width – Standard (in/mm) 46.7/1186
Overall Width – Wide (in/mm) 52.0/1321
Height to Top of Overhead Guard – Standard (in/mm) 86/2185
Height to Top of Overhead Guard – Optional (in/mm) 83/2118
Minimum turning radius (in/mm) 93.7/2380
Weight with two stage mast (lbs/kg) 10357/4698
Front Tire Size 28×9-15
Rear Tire Size 6.5×10
Wheelbase (in/mm) 66.9/1700
