| Attribute | Value |
|---|---|
| Make | Yale |
| Model | GLP050VX |
| Forklift Type | Pneumatic Tire |
| Basic Capacity (lbs/kg) | 5000/2268 |
| Load Center (in/mm) | 24/610 |
| Power | LP Gas/Dual Fuel |
| Engine | PSI 2.4L / Kubota 2.5L |
| Tire Type | Pneumatic |
| Tilt (forward/back) | 6.0/6.0 degrees |
| Length to Fork Face (in/mm) | 100.7/2559 |
| Overall Width (in/mm) | 45.6/1157 |
| Overall Width - Wide Tread (in/mm) | 51.9/1317 |
| Height to Top of Overhead Guard | 85/2160 |
| Minimum turning radius (in/mm) | 87.2/2216 |
| Weight with two stage mast (lbs/kg) | 8399/3810 |
| Front Tire Size | 7.00 x 12 - 12 |
| Rear Tire Size | 6.00 x 9 |
| Wheelbase (in/mm) | 63.9/1623 |
Affordable ForkliftsLooking for affordable used Yale forklifts?
We have high-quality, ready-to-ship used forklifts at affordable prices in our 30,000 sq ft Ohio warehouse.
Brad Tusup –
iS THE CAPACITY THE SAME FOR THIS FORKLIFT WITH 8 lf FOR EXTENSIONS?
Andy Guild –
The capacity will change. This forklift has a basic capacity of 5000lbs at a 24″ load center. That’s with no attachments and standard 42″ forks. Accessories such as attachments, fork extensions, and longer forks will not only lower the capacity by the weight of those items but also by how they change the load distance from the forklift.
Andy Guild –
Use this section to ask questions and post comments about the Yale GLP050VX forklift.
