| Attribute | Value |
|---|---|
| Make | Yale |
| Model | GLP040SVX |
| Type | Pneumatic Tire Internal Combustion |
| Basic Capacity (lbs/kg) | 4000/1814 |
| Load Center (in/mm) | 24/610 |
| Power | LP Gas |
| Engine | PSI 2.0L |
| Tire Type | Pneumatic |
| Tilt (forward/back) | 6.0/6.0 degrees |
| Length to Fork Face (in/mm) | 89.4/2271 |
| Overall Width - Standard (in/mm) | 42/1068 |
| Overall Width - Wide (in/mm) | 48.7/1238 |
| Height to Top of Overhead Guard - Standard (in/mm) | 84.6/2149 |
| Height to Top of Overhead Guard - Optional (in/mm) | 81.9/2081 |
| Minimum turning radius (in/mm) | 78.1/1985 |
| Weight with two stage mast (lbs/kg) | 6884/3122 |
| Front Tire Size | 6.50 x 10-10 |
| Rear Tire Size | 5.00 x 8.00 |
| Wheelbase (in/mm) | 54.5/1385 |
Affordable ForkliftsLooking for affordable used Yale forklifts?
We have high-quality, ready-to-ship used forklifts at affordable prices in our 30,000 sq ft Ohio warehouse.
