Forklift Specifications
| Attribute | Value |
|---|---|
| Make | Yale |
| Model | ESC040AD |
| Forklift Type | Stand Up Electric |
| Basic Capacity (lb/kg) | 4000/1814 |
| Load Center (in/mm) | 24/609 |
| Power | Electric – 36 Volts |
| Tilt – standard (forward/back) | 5/5 degrees |
| Length to Fork Face (in/mm) | 69.3/1759 |
| Overall Width (in/mm) | 42/1067 |
| Overhead Guard Height – Standard (in/mm) | 88/2234 |
| Turning Radius (in/mm) | 57.4/1458 |
| Truck Weight without battery (lb/kg) | 6801/3085 |
| Drive Tire Size (in) | 18 x 7 – 12.1 |
| Steer Tire Size (in) | 10 x 5 – 6.5 |
Related Products
Mollit consequat adipisicing in commodo fugiat. Quis voluptate pariatur ex mollit exercitation.
36 Volt Battery Information – 18 Inches
| Attribute | Value |
|---|---|
| Compartment Dimensions – in(mm) | 38.60" x 18.30" x 31.10" |
| Max Amp Hours | 1085 |
| Minimum Weight – lb(kg) | 2300 |
36 Volt Battery Information – 21 Inches
| Attribute | Value |
|---|---|
| Compartment Dimensions – in(mm) | 38.60" x 20.80" x 31.10" |
| Max Amp Hours | 1240 |
| Minimum Weight – lb(kg) | 2695 |
