| Attribute | Value |
|---|---|
| Make | Yale |
| Model | ERP070VL |
| Forklift Type | Four Wheel Electric |
| Basic Capacity (lbs/kg) | 7000/3175 |
| Load Center (in/mm) | 24/610 |
| Power | Electric |
| Battery Type | Lead Acid |
| Tire Type | Pneumatic Shaped Solid |
| Tilt - standard (forward/back) | 5.0/5.0 degrees Length to Fork Face (in/mm): 161.2/2570 |
| Width - standard tires (in/mm) | 46.9/1192 |
| Width - wide tread (in/mm) | 51.5/1308 |
| Height to Top of Overhead Guard without battery rollers (in/mm) | 86.3/2193 |
| Height to Top of Overhead Guard with battery rollers (in/mm) | 90.4/2297 |
| Turning radius (in/mm) | 84.2/2139 |
| Weight without battery (lbs/kg) | 7420/3366 |
| Front Tire Size | 23x10 -12 |
| Rear Tire Size | 18x7 - 8 |
| Wheelbase (in/mm) | 68.9/1750 |
80 Volts
| Attribute | Value |
|---|---|
| Box Dimensions | 40.70" x 33.90" x 31.20" |
| Minimum Weight | 4500lbs |
| Max Amp Hours | 625 |
Affordable ForkliftsLooking for affordable used Yale forklifts?
We have high-quality, ready-to-ship used forklifts at affordable prices in our 30,000 sq ft Ohio warehouse.
Andy Guild –
Use this section to ask questions and leave comments about the Yale ERP070VL forklift.
