| Attribute | Value |
|---|---|
| Make | Yale |
| Model | ERP035VT |
| Forklift Type | Three Wheel Electric Rider |
| Basic Capacity (lbs/kg) | 3500/1588 |
| Load Center (in/mm) | 24/610 |
| Power | Electric - 36/48 Volts |
| Battery Type | Lead Acid |
| Tilt - standard (forward/back) | 5.0/5.0 degrees |
| Length to Fork Face (in/mm) | 74.9/1903 |
| Width - standard tires (in/mm) | 41.3/1050 |
| Height to Top of Overhead Guard | Std (in/mm): 81.5/2070 Flat Plate (in/mm): 77.9/1979 Drive in Rack (in/mm): 81.5/2070 |
| Turning radius (in/mm) | 62.1/1577 |
| Right Angle Stack (in/mm) | 122.7/3117 |
| Weight without battery (lbs/kg) | 5230/2372 |
| Front Tire Size | 18 x 7-8 |
| Rear Tire Size | 15 x 4.5-8 |
| Wheelbase (in/mm) | 54.6/1386 |
36 Volts
| Attribute | Value |
|---|---|
| Box Dimensions | 39.00" x 25.30" x 23.90" |
| Minimum Weight | 2100lbs |
| Max Amp Hours | 1100 |
36 Volts - No Platform
| Attribute | Value |
|---|---|
| Box Dimensions | 39.00" x 25.30" x 26.70" |
| Minimum Weight | 2500lbs |
| Max Amp Hours | 1100 |
48 Volts
| Attribute | Value |
|---|---|
| Box Dimensions | 39.00" x 25.30" x 23.90" |
| Minimum Weight | 2100lbs |
| Max Amp Hours | 770 |
48 Volts - No Platform
| Attribute | Value |
|---|---|
| Box Dimensions | 39.00" x 25.30" x 26.70" |
| Minimum Weight | 2500lbs |
| Max Amp Hours | 770 |
