| Make | Yale |
| Model | ERC065VG |
| Basic Capacity (lbs/kg) | 6500/2948 |
| Load Center (in/mm) | 24/610 |
| Power | Electric |
| Battery Type | Lead Acid |
| Tire Type | Cushion Drive, Cushion Steer |
| Tilt - standard (forward/back) | 5.0/5.0 degrees Length to Fork Face - 36" Battery Box (in/mm): 90/2285 |
| Length to Fork Face - 40" Battery Box (in/mm) | 92.2/2343 |
| Width - standard tires (in/mm) | 43.6/1108 |
| Width - wide tread (in/mm) | 48.9/1242 |
| Height to Top of Overhead Guard Std (in/mm) | 88.5/2248 |
| Turning radius - 36" Battery Box (in/mm) | 79.1/2008 |
| Turning Radius - 40" Battery Box (in/mm) | 81.7/2074 |
| Weight without battery - 36" Battery Box (lbs/kg) | 7400/3357 |
| Weight without battery - 40" Battery Box (lbs/kg) | 7040/3193 |
| Front Tire Size | 21x8x15 |
| Rear Tire Size | 16x6x10.5 |
| Wheelbase - 36" Battery Box (in/mm) | 57.6/1463 |
| Wheelbase - 40" Battery Box (in/mm) | 60.8/1545 |
