Forklift Specifications
| Attribute | Value |
|---|---|
| Make | Toyota |
| Model | 9BRU18 |
| Forklift Type | Single Reach Truck |
| Load Capacity (lb/kg) | 3500/1580 |
| Load Center (in/mm) | 24/610 |
| Wheelbase – 14.5" Battery Box (in/mm) | 57.1/1450 |
| Wheelbase – 16.5" Battery Box (in/mm) | 59.1/1501 |
| Wheelbase – 18.5" Battery Box (in/mm) | 61.1/1552 |
| Fuel | Electric – 24 or 36 Volts |
| Length to Fork Face – 14.5" Battery Box (in/mm) | 55.3/1405 |
| Length to Fork Face – 16.5" Battery Box (in/mm) | 57.3/1430 |
| Length to Fork Face – 18.5" Battery Box (in/mm) | 59.3/1506 |
| Length to End of Base Legs – 14.5"Battery Box (in/mm) | 76.2/1935 |
| Length to End of Base Legs – 16.5"Battery Box (in/mm) | 78.2/1986 |
| Length to End of Base Legs – 18.5"Battery Box (in/mm) | 80.2/2037 |
| Tilt Range – Forward/Back (degrees) | 3/4.5 |
| Outside Turning Radius – 14.5" Battery Box (in/mm) | 70.8/1798 |
| Outside Turning Radius – 16.5" Battery Box (in/mm) | 72.8/1849 |
| Outside Turning Radius – 18.5" Battery Box (in/mm) | 74.8/1900 |
| Drive Wheel Size (in/mm) | 13.5×6.0 / 345×152.4 |
| Caster Wheel Size (in/mm) | 8×4 / 203×102 |
| Load Wheel Size (in/mm) | 5×3.63 / 127×92 |
Toyota 9BRU18 Battery and Charger Information
Mollit consequat adipisicing in commodo fugiat. Quis voluptate pariatur ex mollit exercitation.
36 Volts – 14.5" Battery Box
| Attribute | Value |
|---|---|
| Forklift Battery Box Dimensions | 38.62" x 14.50" x 31.00" |
| Amp Hour Capacity | 625Ah |
| Minimum Weight | 1600lbs |
36 Volts 16.5" Battery Box
| Attribute | Value |
|---|---|
| Forklift Battery Box Dimensions | 38.62" x 16.50" x 31.00" |
| Amp Hour Capacity | 750ah |
| Minimum Weight | 2300lbs |
36 Volts – 18.5" Battery Box
| Attribute | Value |
|---|---|
| Box Dimensions | 38.62" x 18.50" x 31.00" |
| Amp Hour Capacity | 875 |
| Minimum Weight | 2300lbs |
