Toyota 8FGCU18

Attribute Value
Make Toyota
Model 8FGCU18
Type Cushion Tire
Basic Capacity (lb/kg) 3500/1600
Power LP Gas
Load Center (in/mm) 24/610
Tire Type Cushion
Length to Fork Face (in/mm) 84.6/2150
Overall Width – Standard Tires (in/mm) 37.2/945
Height to Top of Overhead Guard – Standard (in/mm) 80.1/2035
Rear Overhang – in/mm: 18.3/465
Turning radius (inside/outside) – in/mm 70/1780
Weight with two stage mast – lb/kg 6410 (2910)
Front Tire Size 18.0 x 6.0 x 12.125
Rear Tire Size 14.0 x 4.5 x 8
Wheelbase – in/mm 48.2/1225
Engine Toyota 4Y – ECS
Cylinders 4
Horsepower 48
