Forklift Specifications
| Attribute | Value |
|---|---|
| Make | Toyota |
| Model | 8FBCU32 |
| Forklift Type | Four Wheel Electric Rider |
| Basic Capacity (lbs/kg) | 6500/2950 |
| Load Center (in/mm) | 24/610 |
| Power | Electric – 36/48 Volts |
| Battery Type | Lead Acid |
| Tire Type | Cushion Drive, Cushion Steer |
| Tilt – standard (forward/back) | 6/8 degrees |
| Length to Fork Face (in/mm) | 91.3/2320 |
| Width – standard tires (in/mm) | 43.7/1110 |
| Height to Top of Overhead Guard (in/mm) | 88/2235 |
| Turning radius (in/mm) | 78.7/2000 |
| Right Angle Stack (in/mm) | 96.4/2450 |
| Weight without battery (lbs/kg) | 8130/3685 |
| Front Tire Size | 21x7x15 |
| Rear Tire Size | 16x5x10.5 |
| Wheelbase (in/mm) | 54.7/1390 |
Related Products
Mollit consequat adipisicing in commodo fugiat. Quis voluptate pariatur ex mollit exercitation.
36 Volts
| Attribute | Value |
|---|---|
| Minimum Weight | 3000lbs |
| Recommended Amp Hours | 1190 AH |
| Box Dimensions | 39.1" x 34.3" x 23.8" |
| Connector | SB350 / Gray |
48 Volts
| Attribute | Value |
|---|---|
| Minimum Weight | 3000lbs |
| Recommended Amp Hours | 850 AH |
| Box Dimensions | 39.1" x 34.3" x 23.8" |
| Connector | SB350 / Gray |
Used Forklifts, Fair Prices
Looking for affordable used Toyota forklifts?
We have high-quality, ready-to-ship used forklifts at affordable prices in our 30,000 sq ft Ohio warehouse.
Hi I am looking battery charger for Toyota 8FBCU32
Does the Toyota 8FBCU32 Forklift include a charger? if not, what is the P/N for the charger? Please advise, Thank you!
Thanks for the comment. This page is just for general information and is not a machine for sale. And the charger this machine requires depends on what battery is installed – there are options when buying new and used. And the charger also depends on the power requirements of the facility where the forklift is being used.
