Forklift Specifications
Attribute | Value |
---|---|
Make | Toyota |
Model | 8FBCU25 |
Forklift Type | Four Wheel Electric Rider |
Basic Capacity (lbs/kg) | 5000/2500 |
Load Center (in/mm) | 24/610 |
Power | Electric – 36/48 Volts |
Battery Type | Lead Acid |
Tire Type | Cushion Drive, Cushion Steer |
Tilt – standard (forward/back) | 6/8 degrees |
Length to Fork Face (in/mm) | 84.3/2140 |
Width – standard tires (in/mm) | 41.9/1065 |
Height to Top of Overhead Guard (in/mm) | 88/2235 |
Turning radius (in/mm) | 70.9/1800 |
Right Angle Stack (in/mm) | 87.6/2225 |
Weight without battery (lbs/kg) | 6960/3155 |
Front Tire Size | 21x7x15 |
Rear Tire Size | 16x5x10.5 |
Wheelbase (in/mm) | 51/1295 |
Toyota 8FBCU25 Forklift Battery and Charger Information and Purchase Options
Mollit consequat adipisicing in commodo fugiat. Quis voluptate pariatur ex mollit exercitation.
36 Volts – 8FBCU25 Battery & Charger Specs & Products
Attribute | Value |
---|---|
Minimum Weight | 2600lbs |
Max Amp Capacity | 1320 |
Box Dimensions | 39.1" x 30.5" x 23.8" |
Connector | SB350 / Gray |
Position | B |
48 Volts – 8FBCU25 Battery & Charger Specs & Products
Attribute | Value |
---|---|
Minimum Weight | 2200lbs |
Max Amp Capacity | 990 |
Box Dimensions | 39.1" x 30.5" x 23.8" |
Connector | SB350 / Gray |
Position | B |
Used Forklifts, Fair Prices
Looking for affordable used Toyota forklifts?
We have high-quality, ready-to-ship used forklifts at affordable prices in our 30,000 sq ft Ohio warehouse.

Just doing some research and looking to add lift. Will this lift run on either a 36 volt or 48 volt battery?
The Toyota 8FBCU25 can be 36 or 48 volts. It’s an option from the factory and can’t be changed after it’s built.
Looking to get a quote for a forlklift “Toyota Model 8FBCU25″also need:
Battery: New Industrial 36V battery with single point watering system, low water monitor, and direct fill link and full 5-year warranty.
Battery Charger: New Impaq Industrial 3 phase 480V 36V charger.
LOOKING TO PURCHASE ELECTRIC FORKLIFTS FOR MY SHOP. I’M INTERESTED IN PURCHASING 3 FORKLIFTS.
WITH CHARGE STATION INCLUDED
Thanks for the message. We’ll email you some options.
