Forklift Specifications
| Attribute | Value |
|---|---|
| Make | Toyota |
| Model | 7FBEU20 |
| Forklift Type | Three Wheel Electric Rider |
| Basic Capacity (lbs/kg) | 4000/1814 |
| Load Center (in/mm) | 24/610 |
| Power | Electric – 36/48 Volts |
| Battery Type | Lead Acid |
| Tire Type | Cushion Drive, Cushion Steer |
| Tilt – standard (forward/back) | 5/6.5 degrees |
| Length to Fork Face (in/mm) | 77.2/1961 |
| Width – standard tires (in/mm) | 41.5/1054 |
| Height to Top of Overhead Guard (in/mm) | 78/1981 |
| Turning radius (in/mm) | 62.8/1595 |
| Right Angle Stack (in/mm) | 772/1961 |
| Weight without battery (lbs/kg) | 5125/22324 |
| Front Tire Size | 18x7x12-1/8 |
| Rear Tire Size | 15x5x11-1/4 |
| Wheelbase (in/mm) | 51/1295 |
Related Products
Mollit consequat adipisicing in commodo fugiat. Quis voluptate pariatur ex mollit exercitation.
36 Volts
| Attribute | Value |
|---|---|
| Minimum Weight | 2105lbs |
| Recommended Capacity | 765AH |
| Box Dimensions | 39.2" x 25.10" x 24.10" |
| Connector | SB350 / Gray |
| Position | B |
48 Volts
| Attribute | Value |
|---|---|
| Minimum Weight | 1650 lbs |
| Recommended Amp Capacity | 660 |
| Box Dimensions | 39.2" x 25.10" x 24.10" |
| Connector | SB350 / Gray |
| Position | B |
Used Forklifts, Fair Prices
Looking for affordable used Toyota forklifts?
We have high-quality, ready-to-ship used forklifts at affordable prices in our 30,000 sq ft Ohio warehouse.
What is the IP rating for this forklift
We were unable to find that information. You’re best bet is to call your nearest Toyota forklift dealership who might have that info or can call their manufacturers rep to track it down.
