| Attribute | Value |
|---|---|
| Make | Raymond |
| Model | 540-OPC30TT |
| Forklift Type | Order Picker |
| Basic Capacity (lbs/kg) | 3000/1350 |
| Load Center (in/mm) | 24/610 |
| Power | Electric - 24 Volts |
| Battery Type | Lead Acid |
| Tilt - standard (forward/back) | None |
| Length to Fork Face (in/mm) | 75/1905 |
| Width (in/mm) | 40/1016 |
| Height to Top of Overhead Guard (in/mm) | 87.63/2226 |
| Drive Wheel | 12x5x9 |
24 Volts - 13" Compartment
| Attribute | Value |
|---|---|
| Amp Hour Capacity | 750 |
| Box Dimensions | 31.00" x 13.00" x 30.88" |
| Minimum Weight | 920lbs |
24 Volts - 14" Compartment
| Attribute | Value |
|---|---|
| Amp Hour Capacity | 875 |
| Box Dimensions | 36.38" x 14.12" x 30.88" |
| Minimum Weight | 1600lbs |
Affordable ForkliftsLooking for affordable used Raymond forklifts?
We have high-quality, ready-to-ship used forklifts at affordable prices in our 30,000 sq ft Ohio warehouse.
Robert Campos –
Looking for order picker that reach 300″ and are wire guided. Please let me know if you have any in stock.
Thanks
Andy Guild –
Thanks for the message. We don’t have anything in stock. But if something comes in we’ll reach out.
