| Attribute | Value |
|---|---|
| Make | Raymond |
| Model | 450-C40TT |
| Forklift Type | Three Wheel Electric Rider |
| Basic Capacity | 4000 lbs |
| Load Center | 24" |
| Power | Electric |
| Tire Type | Cushion |
| Tilt (forward/back) | 5.0/6.0 degrees |
| Length to Fork Face (in/mm) | 81.6/2072 |
| Width - standard tires (in/mm) | 41.3/1050 |
| Height to Top of Overhead Guard (in/mm) | 79/2007 |
| Right-Angle Stack w/pallet LxW=48”x40” (in/mm) | 133.9/3400 |
| Weight without battery & Three Stage Mast (lbs/kg) | 7034/3191 |
| Front Tire Size (in/mm) | 18.0 x 7.0 / 457x178 |
| Rear Tire Size (in/mm) | 16.0 x 6.0 / 406x152 |
| Wheelbase (in/mm) | 55.7/1415 |
36 Volts
| Attribute | Value |
|---|---|
| Minimum Weight | 2050lbs |
| Max Amp Capacity | 1100 |
| Box Dimensions | 38.80" x 24.94" x 23.00" |
| Connector | SB350 / Gray |
| Position | B |
48 Volts
| Attribute | Value |
|---|---|
| Minimum Weight | 2050 lbs |
| Max Amp Capacity | 850 |
| Box Dimensions | 38.80" x 24.94" x 23.00" |
| Connector | SB350 / Gray |
| Position | B |
Affordable ForkliftsLooking for affordable used Raymond forklifts?
We have high-quality, ready-to-ship used forklifts at affordable prices in our 30,000 sq ft Ohio warehouse.
