Forklift SpecificationsMitsubishi FBC30LN2
| Attribute | Value |
|---|---|
| Make | Mitsubishi |
| Model | FBC30LN2 |
| Basic Capacity (lbs/kg) | 6500/2950 |
| Load Center (in/mm) | 24/600 |
| Power | Electric - 36/48 Volts |
| Battery Type | Lead Acid |
| Tire Type | Cushion |
| Tilt (forward/back) | 5.0/5.0 degrees |
| Length to Fork Face (in/mm) | 88.8/2255 |
| Overall Width - Standard Tires (in/mm) | 43.5/1103 |
| Height to Top of Overhead Guard | 87.0/2230 |
| Minimum turning radius (in/mm) | 79.5/2020 |
| Weight w/minimum weight battery (lbs/kg) | 11090/5030 |
| Front Tire Size | 21.0 x 8.0 x 15.0 |
| Rear Tire Size | 16.0 x 6.0 x 10.5 |
| Wheelbase (in/mm) | 54.3/1380 |
36 Volts
| Attribute | Value |
|---|---|
| Amp Hour Capacity | 1190 |
| Box Dimensions | 39.50" x 34.40" x 23.30" |
| Minimum Weight | 3100 lbs |
48 Volts
| Attribute | Value |
|---|---|
| Amp Hour Capacity | 850 |
| Box Dimensions | 39.50" x 34.40" x 23.30" |
| Minimum Weight | 3100 lbs |
