Forklift SpecificationsJungheinrich ETG230
| Attribute | Value |
|---|---|
| Make | Jungheinrich |
| Model | ETG230 |
| Forklift Type | Stand Up Electric Counterbalance |
| Fuel Type | Electric |
| Voltage | 36 |
| Capacity (lb/kg) | 3000/1360 |
| Load Center (in/mm) | 24/600 |
| Tilt Angle - Forward/Backward | 3/5 degrees |
| Length To Fork Face (in/mm) | 67.5/1715 |
| Overall Chassis Width (in/mm) | 41/1040 |
| Minimum Outside Turning Radius (in/mm) | 55.5/1410 |
| Travel Speed (mph/kph) | 7.7/12.4 |
| Gradeability - loaded or empty | 15% |
| Tire Size - Drive (in/mm) | 16.25x7 / 413x178 |
| Tire Size - Steer (in/mm) | 10.5x4 / 267x102 |
| Battery Compartment Dimensions LxWxH (in/mm) | 16.3x38.9x31.7 / 413x990x805 |
14" Compartment - 36 Volts
| Attribute | Value |
|---|---|
| Min Weight | 1700 lbs |
| Max Amp | 775 |
| Battery Compartment Size | 38.60" x 14.25" x 31.70" |
16" Compartment - 36 Volts
| Attribute | Value |
|---|---|
| Min Weight | 2000 lbs |
| Battery Compartment Size | 38.90" x 16.30" x 31.70" |
18" Compartment - 36 Volts
| Attribute | Value |
|---|---|
| Min Weight | 2300lbs |
| Battery Compartment Size | 38.60" x 18.25" x 31.70" |
