Forklift SpecificationsJungheinrich EFG220
| Attribute | Value |
|---|---|
| Make | Jungheinrich |
| Model | EFG220 |
| Forklift Type | Three Wheel Electric Rider |
| Basic Capacity | 4000 lbs |
| Load Center | 24" |
| Power | Electric |
| Tilt (forward/back) | 7.0/7.0 degrees |
| Length to Fork Face | 78.5" |
| Width (standard tires) | 44.1" |
| Height to Top of Overhead Guard | 80.4" |
| Minimum turning radius | 65.2" |
| Weight with min weight battery | 7343lbs |
| Front Tire Size | 200/50-10 |
| Rear Tire Size | 140/55-9 |
| Wheelbase | 57.7" |
36 Volts
| Attribute | Value |
|---|---|
| Min Weight | 2147 lbs |
| Amp Hour Capacity | 765 |
| Battery Compartment Size | 32.68" x 29.06" x 24.69" |
48 Volts
| Attribute | Value |
|---|---|
| Min Weight | 2147 lbs |
| Amp Hour Capacity | 510 |
| Battery Compartment Size | 32.68" x 29.06" x 24.69" |
Affordable ForkliftsLooking for affordable used Jungheinrich forklifts?
We have high-quality, ready-to-ship used forklifts at affordable prices in our 30,000 sq ft Ohio warehouse.
Andy Guild –
Error code 1901.1 when we started the machine. We could use the mast functions but the forklift wouldn’t drive. Code is for “drive pedal activated during startup.” Seems like the pedal was stuck down slightly so we pulled it up and the code went away.
