Make | Hyster |
Model | S60FT |
Type | Cushion Tire Internal Combustion |
Basic Capacity (lbs/kg) | 6000/2722 |
Load Center (in/mm) | 24/610 |
Power | LPG |
Engine | PSI 2.4L/Kubota 2.5L |
Tire Type | Cushion Drive, Cushion Steer |
Tilt - standard (forward/back) | 5/5 degrees |
Length to Fork Face (in/mm) | 93.4/2373 |
Width - standard tires (in/mm) | 43.6/1108 |
Width - wide tread tires (in/mm) | 48.9/1242 |
Height to Top of Overhead Guard Standard (in/mm) | 84/2128 |
Turning radius (in/mm) | 81.3/2066 |
Right Angle Stack (in/mm) | 97.2/2468 |
Weight with 2-StageLFL Mast(lbs/kg) | 9768/4431 |
Front Tire Size | 21x8x15 |
Rear Tire Size | 16x6x10.5 |
Wheelbase (in/mm) | 56.3/1430 |
Andy Guild –
Use this section to ask questions and leave comments about the Hyster S60FT forklift.
