| Attribute | Value |
|---|---|
| Make | Hyster |
| Model | S100FTBCS |
| Type | Cushion Tire Internal Combustion |
| Basic Capacity (lbs/kg) | 10000/4545 |
| Load Center (in/mm) | 24/610 |
| Power | LPG |
| Engine | GM 4.3L |
| Tire Type | Cushion Drive, Cushion Steer |
| Tilt - standard (forward/back) | 5/6 degrees |
| Length to Fork Face (in/mm) | 101.6/2581 |
| Width - standard tires (in/mm) | 52.0/1320 |
| Width - wide tread tires (in/mm) | 55.9/1420 |
| Height to Top of Overhead Guard Standard (in/mm) | 86/2175 |
| Turning radius (in/mm) | 87.9/2232 |
| Right Angle Stack (in/mm) | 106.1/2694 |
| Weight with 2-StageLFL Mast(lbs/kg) | 16625/7541 |
| Front Tire Size | 22x12x16 |
| Rear Tire Size | 18x8x12.2 |
| Wheelbase (in/mm) | 61.8/1570 |
Affordable ForkliftsLooking for affordable used Hyster forklifts?
We have high-quality, ready-to-ship used forklifts at affordable prices in our 30,000 sq ft Ohio warehouse.
