Attribute | Value |
---|---|
Make | Hyster |
Model | R30XMS3 |
Forklift Type | Order Picker |
Basic Capacity (lbs/kg) | 3000/1361 |
Load Center (in/mm) | 24/610 |
Power | Electric - 24V Battery Type: Lead Acid |
Tire Type | Poly Length to Face of Operator Deck: Two Stage Mast (in/mm): 71.3/1812 |
Three Stage Mast (in/mm) | 72.3/1837 |
Base Width 41" - Guide Roller Width (in/mm) | 48.3/1226 |
Base Width 48" - Guide Roller Width (in/mm) | 55/1397 |
Height to Top of Overhead Guard Standard (in/mm) | 80.4/2042 |
Turning radius (in/mm) | 66.2/1681 Clear Aisle Width: 2 Stage Mast (in/mm): 120.6/3063 |
3 Stage Mast (in/mm) | 121.7/3091 |
Weight w/o battery (lbs/kg) | 4266/1935 |
Drive Tire Size | 12/5.5 |
Rear Tire Size | 4.0/3.0 |
Wheelbase (in/mm) | 55.5/1410 |
