| Attribute | Value |
|---|---|
| Make | Hyster |
| Model | H100FT |
| Type | Pneumatic Tire Internal Combustion |
| Basic Capacity (lbs/kg) | 10000/4536 |
| Load Center (in/mm) | 24/610 |
| Power | LPG/Gasoline/Diesel |
| Engine | Kubota 3.8L LPG/Dual Fuel/Diesel |
| Tire Type | Pneumatic |
| Tilt - standard (forward/back) | 6/10 degrees |
| Length to Fork Face (in/mm) | 127.8/3247 |
| Width - standard tires (in/mm) | 57.1/1450 |
| Width - wide tread tires (in/mm) | 62.0/1575 |
| Height to Top of Overhead Guard Standard (in/mm) | 91/2302 |
| Height to Top of Overhead Guard Optional (in/mm) | 88/2235 |
| Turning radius (in/mm) | 111.7/2837 |
| Right Angle Stack (in/mm) | 134.8/3425 |
| Weight with 2-StageLFL Mast(lbs/kg) | 15108/6853 |
| Front Tire Size | 300 x 15 - 20 Ply |
| Rear Tire Size | 7.00 x 12 -14 Ply |
| Wheelbase (in/mm) | 82.7/2100 |
Affordable ForkliftsLooking for affordable used Hyster forklifts?
We have high-quality, ready-to-ship used forklifts at affordable prices in our 30,000 sq ft Ohio warehouse.
