| Make | Hyster |
| Model | E50XN-27 |
| Type | Four Wheel Electric |
| Basic Capacity (lbs/kg) | 5000/2268 |
| Load Center (in/mm) | 24/610 |
| Power | Electric |
| Tire Type | Cushion Drive, Cushion Steer |
| Tilt - standard (forward/back) | 5/5 degrees |
| Length to Fork Face (in/mm) | 80.3/2040 |
| Width - Standard (in/mm) | 42.1/1070 |
| Width - Wide Tread (in/mm) | 48.9/1242 |
| Height to Top of Overhead Guard Standard (in/mm) | 88.5/2248 |
| Turning radius (in/mm) | 69.2/1757 |
| Right Angle Stack (in/mm) | 132.5/3366 |
| Weight with 2-StageLFL Mast - no batt (lbs/kg) | 7030/3189 |
| Front Tire Size - standard | 21 x 7 x 15 |
| Rear Tire Size - standard | 16 x 5 x 10.5 |
| Wheelbase (in/mm) | 48.4/1230 |
Andy Guild –
Use this section to ask questions and leave comments about the Hyster E50XN-27 forklift.
