| Attribute | Value |
|---|---|
| Make | Hyster |
| Model | E35HSD3 |
| Forklift Type | Stand Up Electric |
| Capacity (lb/kg) | 3500/1588 |
| Fuel Type | Electric - 36 Volts |
| Load Center (in/mm) | 24/610 |
| Tilt Standard (degrees) | 5 Forward / 5 Back |
| Tilt Optional (degrees) | 10 Forward / 5 Back |
| Overhead Guard Height - Standard (in/mm) | 88/2234 |
| Overhead Guard Height - Optional (in/mm) | 83/2108 |
| Overall Width (in/mm) | 42/1067 |
| Standard Carriage Width (in/mm) | 38.5/978 |
| Length To Face of Forks (in/mm) | 69.3/1759 |
| Wheelbase (in/mm) | 46.3/1177 |
| Turning Radius (in/mm) | 57.4/1458 |
36 Volts - 18" Box
| Attribute | Value |
|---|---|
| Box Dimensions | 38.60" x 18.30" x 31.10" |
| Max Amp Hours | 1085 |
| Minimum Weight | 2300 |
36 Volts - 21" Box
| Attribute | Value |
|---|---|
| Box Dimensions | 38.60" x 20.80" x 31.10" |
| Max Amp Hours | 1240 |
| Minimum Weight | 2500 |
