| Attribute | Value |
|---|---|
| Make | Crown |
| Model | SC5245-40 |
| Type | Three Wheel Electric Sit Down |
| Load Capacity (lb/kg) | 4000/1814 |
| Power | 36/48V |
| Load Center (in/mm) | 24/600 |
| Tire Type | Cushion |
| Fork Carriage | ITA Class II |
| Tilt (forward/back) | 5/5 degrees |
| Width (in/mm) | 42/1067 |
| Length to Fork Face (in/mm) | 77.2/1960 |
| Height (in/mm) | 83/2110 |
| Turning Radius (in/mm) | 62.7/1595 |
| Weight without battery (lb/kg) | 6260/2840 |
| Front Tires | 18x7x12.1" |
| Rear Tires | 15x5x11.25" |
| Wheelbase (in/mm) | 54.7/1390 |
36V - 23" Battery Compartment
| Attribute | Value |
|---|---|
| Amp Hour Capacity | 765 |
| Compartment Dimensions | 38.69" x 22.56" x 22.62" |
| Minimum Weight | 2100lbs |
36V - 25" Battery Compartment
| Attribute | Value |
|---|---|
| Amp Hour Capacity | 850 |
| Compartment Dimensions | 38.81" x 25.13" x 22.80" |
| Minimum Weight | 2250lbs |
48V - 23" Battery Compartment
| Attribute | Value |
|---|---|
| Amp Hour Capacity | 595 |
| Compartment Dimensions | 38.69" x 22.62" x 22.80" |
| Minimum Weight | 2100lbs |
