| Attribute | Value |
|---|---|
| Make | Cat |
| Model | GC40K |
| Forklift Type | Cushion Tire - Internal Combustion |
| Basic Capacity | 8000 lbs |
| Load Center | 24" |
| Power | LP Gas |
| Tire Type | Cushion |
| Tilt (forward/back) | 5.0/10.0 degrees |
| Length to Fork Face | 100.4" |
| Width (standard tires) | 46.5" |
| Height to Top of Overhead Guard | 83.5" |
| Minimum turning radius | 90.0" |
| Weight | 12280lbs |
| Front Tire Size | 22.0 x 9.0 x 16.0" |
| Rear Tire Size | 18.0 x 7.0 x 12.1" |
| Wheelbase | 62.0" |
| Engine | GM V6 |
Affordable ForkliftsLooking for affordable used Cat forklifts?
We have high-quality, ready-to-ship used forklifts at affordable prices in our 30,000 sq ft Ohio warehouse.
Dylan –
I’m looking for the TPS and cannot find it anywhere, all I’ve found is 3 wired when the model I have is 6. Model number GC40K-LP.
