| Attribute | Value |
|---|---|
| Make | Cat |
| Model | ET4000 |
| Forklift Type | Three Wheel Electric Rider |
| Basic Capacity | 4000 lbs |
| Load Center | 24" |
| Power | Electric |
| Tilt (forward/back) | 7.0/7.0 degrees |
| Length to Fork Face | 78.5" |
| Width (standard tires) | 44.1" |
| Height to Top of Overhead Guard | 80.4" |
| Minimum turning radius | 65.2" |
| Weight with min weight battery | 7343lbs |
| Front Tire Size | 200/50-10 |
| Rear Tire Size | 140/55-9 |
| Wheelbase | 57.7" |
48 Volts
| Attribute | Value |
|---|---|
| Battery Box Dimensions | 29.06 x 32.68 x 24.69" |
| Max Amps | 600 |
| Minimum Battery Weight | 2147 lbs |
| Connector Type | EBC320 / Black |
| Position | A |
Affordable ForkliftsLooking for affordable used Cat forklifts?
We have high-quality, ready-to-ship used forklifts at affordable prices in our 30,000 sq ft Ohio warehouse.
Rubab Fatima –
I want a quote for Caterpillar 2ET4000 36V Electric Pneumatic Tire Lift Truck or equivalent. Triplex Mast with Maximum Fork Height of 188 inches (minimum) while able to maintain an overall Lowered Mast Height of 84 inches (maximum). The mast shall include a load backrest, a hydraulic side shifter, and manual fork spreading capabilities. Fork Dimensions shall be 1.6 inches in height (thickness), 3.9 inches in width, and 45.3 inches in length or equivalent. Maximum Standard Battery (Lead-Acid) Capacity shall be 680 Amp Hours (minimum) calculated using the 6 hour discharge rate. If the manufacturer quoted offers a high capacity lead-acid battery then that option shall be quoted in lieu of the standard capacity battery. Gross weight of quoted forklift with a standard capacity battery and before options are added shall not exceed 7,500 pounds.
Caterpillar 36V Charger compatible with 2ET4000 Lift Truck AND the included battery option quoted or equivalent. The charger shall automatically shut off or switch to a maintenance/float mode when a full charge is reached. The charger shall be capable of overcharging protection to prevent battery damage. Charger input voltage requirements are 208V/240V/480V, 60Hz, 3 phase power.
Rubab Fatima –
I need a quotation for Caterpillar 2ET4000 36V Electric Pneumatic Tire Lift Truck or equivalent having following specs: Triplex Mast with Maximum Fork Height of 188 inches (minimum) while able to maintain an overall Lowered Mast Height of 84 inches (maximum). The mast shall include a load backrest, a hydraulic side shifter, and manual fork spreading capabilities. Fork Dimensions shall be 1.6 inches in height (thickness), 3.9 inches in width, and 45.3 inches in length or equivalent. Maximum Standard Battery (Lead-Acid) Capacity shall be 680 Amp Hours (minimum) calculated using the 6 hour discharge rate. If the manufacturer quoted offers a high capacity lead-acid battery then that option shall be quoted in lieu of the standard capacity battery. Gross weight of quoted forklift with a standard capacity battery and before options are added shall not exceed 7,500 pounds.
Caterpillar 36V Charger compatible with 2ET4000 Lift Truck AND the included battery option quoted or equivalent. The charger shall automatically shut off or switch to a maintenance/float mode when a full charge is reached. The charger shall be capable of overcharging protection to prevent battery damage. Charger input voltage requirements are 208V/240V/480V, 60Hz, 3 phase power.
Tony –
I need a pdf for an operators manual for 2ET4000 model
Andy Guild –
Thanks for the message. We don’t have a PDF available, but we can sell you a new owner’s manual – our parts supplier’s website is down at the moment though. Let me know if you’re interested in buying a new manual.
Andy Guild –
Use this section to ask questions and leave comments about the Cat 2ET4000 forklift.
