| Attribute | Value |
|---|---|
| Make | Cat |
| Model | EP4000 |
| Forklift Type | Electric Sit Down Rider - Four Wheel |
| Basic Capacity | 4000 lbs |
| Load Center | 24" |
| Power | Electric |
| Tire Type | Solid Pneumatic |
| Tilt (forward/back) | 7.0/7.0 degrees |
| Length to Fork Face | 82.6" |
| Width (standard tires) | 44.1" |
| Height to Top of Overhead Guard | 80.4" |
| Minimum turning radius | 78.1" |
| Weight with min weight battery | 7175lbs |
| Front Tire Size | 200/50-10 |
| Rear Tire Size | 16 x 6-8 |
| Wheelbase | 59.4" |
36 Volts
| Attribute | Value |
|---|---|
| Minimum Weight | 2147 lbs |
| Max Amp Capacity | 600 |
| Box Dimensions | 32.68 x 29.09 x 24.69" |
| Connector | EBC320 / Black |
| Position | A |
48 Volts
| Attribute | Value |
|---|---|
| Battery Box Dimensions | 29.06 x 32.68 x 24.69" |
| Max Amps | 600 |
| Minimum Battery Weight | 2147 lbs |
| Connector Type | EBC320 / Black |
| Position | A |
