| Attribute | Value |
|---|---|
| Make | Cat |
| Model | EC25EN2 |
| Forklift Type | Four Wheel Electric Rider |
| Load Center | 24" |
| Basic Capacity | 5000 lbs |
| Power | Electric |
| Tire Type | Cushion |
| Tilt (forward/back) | 5.0/5.0 degrees |
| Length to Fork Face | 85.9" |
| Width (standard tires) | 41.5" |
| Height to Top of Overhead Guard | 87" |
| Minimum turning radius | 77.3" |
| Weight with min weight battery | 9000lbs |
| Front Tire Size | 21.0 x 7.0 x 15.0" |
| Rear Tire Size | 16.0 x 6.0 x 10.5" |
| Wheelbase | 54.3" |
36 Volts
| Attribute | Value |
|---|---|
| Minimum Weight | 3100lbs |
| Max Amp Capacity | 1540 |
| Box Dimensions | 39.5" x 34.4" x 23.3" |
| Connector | SB350 / Gray |
| Position | B |
48 Volts
| Attribute | Value |
|---|---|
| Minimum Weight | 3100lbs |
| Max Amp Capacity | 1140 |
| Box Dimensions | 39.5" x 34.4" x 23.3" |
| Connector | SB350/Gray |
| Position | B |
Affordable ForkliftsLooking for affordable used Cat forklifts?
We have high-quality, ready-to-ship used forklifts at affordable prices in our 30,000 sq ft Ohio warehouse.
