| Attribute | Value |
|---|---|
| Make | Cat |
| Model | 2ET3500 |
| Forklift Type | Three Wheel Electric Sit Down |
| Basic Capacity | 3500 lbs |
| Load Center | 24" |
| Power | Electric |
| Tilt (forward/back) | 7.0/7.0 degrees |
| Length to Fork Face | 78.5" |
| Width (standard tires) | 44.1" |
| Height to Top of Overhead Guard | 80.4" |
| Minimum turning radius | 65.2" |
| Weight with min weight battery | 6957lbs |
| Front Tire Size | 200 / 50-10 |
| Rear Tire Size | 140/55-9 |
| Wheelbase | 57.7" |
48 Volts
| Attribute | Value |
|---|---|
| Battery Box Dimensions | 29.06 x 32.68 x 24.69" |
| Max Amps | 600 |
| Minimum Battery Weight | 2147 lbs |
| Connector Type | EBC320 / Black |
| Position | A |
Affordable ForkliftsLooking for affordable used Cat forklifts?
We have high-quality, ready-to-ship used forklifts at affordable prices in our 30,000 sq ft Ohio warehouse.
