| Attribute | Value |
|---|---|
| Make | Cat |
| Model | 2EP5000 |
| Forklift Type | Four Wheel Electric Rider |
| Basic Capacity | 5000 lbs |
| Load Center | 24" |
| Power | Electric |
| Tire Type | Solid Pneumatic |
| Tilt (forward/back) | 6.0/8.0 degrees |
| Length to Fork Face | 96.1" |
| Width (standard tires) | 47.2" |
| Height to Top of Overhead Guard | 88.2" |
| Minimum turning radius | 84.7" |
| Weight with min weight battery | 10311lbs |
| Front Tire Size | 225 / 75-10 |
| Rear Tire Size | 180/70-8 |
| Wheelbase | 67.7" |
80 Volts
| Attribute | Value |
|---|---|
| Minimum Weight | 3902 lbs |
| Max Amp Capacity | 700 |
| Box Dimensions | 40.47 x 33.66 x 30.87" |
| Connector | EBC320 / Black |
| Position | B |
Affordable ForkliftsLooking for affordable used Cat forklifts?
We have high-quality, ready-to-ship used forklifts at affordable prices in our 30,000 sq ft Ohio warehouse.
Andy Guild –
Use this section to ask questions and leave comments about the Cat 2EP5000 forklift.
