| Attribute | Value |
|---|---|
| Make | Yale |
| Model | ESC030AD |
| Forklift Type | Stand Up Electric |
| Basic Capacity (lb/kg) | 3000/1361 |
| Load Center (in/mm) | 24/609 |
| Power | Electric – 36 Volts |
| Tilt – standard (forward/back) | 5/5 degrees |
| Length to Fork Face 13.8″ Battery Compartment (in/mm) | 62.3/1583 |
| Length to Fork Face 16.0″ Battery Compartment (in/mm) | 64.5/1639 |
| Length to Fork Face 18.3″ Battery Compartment (in/mm) | 66.7/1695 |
| Overall Width (in/mm) | 42/1067 |
| Overhead Guard Height – Standard (in/mm) | 88/2234 |
| Turning Radius -13.8″ Battery Box (in/mm) | 50.7/1289 |
| Turning Radius -16.0″ Battery Box (in/mm) | 52.8/1341 |
| Turning Radius -18.3″ Battery Box (in/mm) | 54.9/1395 |
| Truck Weight without battery – 13.8″ Battery Box (lb/kg) | 6353/2882 |
| Truck Weight without battery – 16.0″ Battery Box (lb/kg) | 6373/2891 |
| Truck Weight without battery – 18.3″ Battery Box (lb/kg) | 6263/2841 |
| Drive Tire Size (in) | 18 x 7 – 12.1 |
| Steer Tire Size (in) | 10 x 5 – 6.5 |
Yale ESC030AD Battery and Charger Information
The Yale ESC030AD forklift has three 36 volt battery options. Learn more and purchase replacement batteries and chargers on our website.
36 Volt 13.8″ Battery Box – Charger and Battery Info
- Power Point 36V 100 Amp Single Phase Charger
- Power Point 36V 100 Amp Three Phase Charger
- Replacement Battery Model – 18-125-11
| ESC030AD 13.8″ Battery Box Specs | |
|---|---|
| Compartment Dimensions – in(mm) | 38.60″ x 13.8″ x 31.10″ |
| Max Amp Hours | 775 |
| Minimum Weight – lb(kg) | 1700 (771) |
36 Volt 16.0″ Battery Box – Charger and Battery Info
- Power Point 36V 140 Amp Single Phase Charger
- Power Point 36V 140 Amp Three Phase Charger
- Replacement Battery Model – 18-125-13
| ESC030AD 16.0″ Battery Box Specs | |
|---|---|
| Compartment Dimensions – in(mm) | 38.60″ x 16.00″ x 30.50″ |
| Max Amp Hours | 930 |
| Minimum Weight – lb(kg) | 1980 (898) |
36 Volt 18.3″ Battery Box – Charger and Battery Info
- Power Point 36V 160 Amp Single Phase Charger
- Power Point 36V 160 Amp Three Phase Charger
- Replacement Battery Model – 18-125-15
| ESC030AD 18.3″ Battery Box Specs | |
|---|---|
| Compartment Dimensions – in(mm) | 38.60″ x 18.30″ x 31.10″ |
| Max Amp Hours | |
| Minimum Weight – lb(kg) | 2300 (1043) |
