| Attribute | Value |
|---|---|
| Make | Toyota |
| Model | 8FBE18U |
| Forklift Type | Three Wheel Electric Rider |
| Basic Capacity (lbs/kg) | 3500/1587 |
| Load Center (in/mm) | 24/610 |
| Power | Electric – 36/48 Volts |
| Battery Type | Lead Acid |
| Tire Type | Cushion or Pneumatic |
| Tilt – standard (forward/back) | 5/6.5 degrees |
| Length to Fork Face (in/mm) | 74.2/1885 |
| Width – Cushion Tires (in/mm) | 41.5/1054 |
| Width – Pneumatic Tires (in/mm) | 42.1/1069 |
| Height to Top of Overhead Guard (in/mm) | 81/2057 |
| Turning radius (in/mm) | 60.5/1537 |
| Right Angle Stack (in/mm) | 74.2/1885 |
| Weight without battery (lbs/kg) | 4990/2263 |
| Front Tire Size (Cushion – Pneumatic) | 18x7x12-1/8 – 18×7-8-16PR |
| Rear Tire Size (Cushion – Pneumatic) | 15x5x11-1/4 – 16×6-8-10PR |
| Wheelbase (in/mm) | 51.6/1310 |
| Error Codes | Toyota Error Codes |
Toyota 8FBE18U Batteries and Chargers
The Toyota 8FBE18U has two 36 volt and two 48 volt options.
36 Volts – 21″
| Attribute | Value |
|---|---|
| Box Dimensions | 39.00″ x 20.70″ x 22.69″ |
| Amp Hour Capacity | 680 |
| Minimum Weight | 1543 lbs |
36 Volts – 22″
| Attribute | Value |
|---|---|
| Box Dimensions | 39.20″ x 21.70″ x 24.50″ |
| Amp Hour Capacity | 680 |
| Minimum Weight | 1543 lbs |
48 Volts – 21″
| Attribute | Value |
|---|---|
| Box Dimensions | 39.00″ x 20.70″ x 23.10″ |
| Amp Hour Capacity | 510 |
| Minimum Weight | 1543 lbs |
48 Volts – 22″
| Attribute | Value |
|---|---|
| Box Dimensions | 39.20″ x 21.70″ x 24.50″ |
| Amp Hour Capacity | 510 |
| Minimum Weight | 1543 lbs |
